Threaded Outlet

Leveraging on our widely spread distribution network, we procure and deal in a high performing range of Threadolets and Stainless Steel Threadolet. Sourced fro authentic vendors, these products find wide applications in pulp & paper mills and fabrication & production of stainless steel products.

These can be availed by the esteemed patrons in a wide spectrum of grades, sizes and classes. Our offered products are widely appreciated in the market for their sturdiness and dimensional accuracy.


Specification

Size: 1/2"NB TO 24"NB IN
Class: 3000 LBS, 6000 LBS, 9000 LBS & Required Schedule
Materials: Stainless Steel Thredolet – SS Thredolet
ASTM A182 F304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L

Duplex Steel Thredolet
ASTM / ASME A/SA 182 UNS F 44, F 45, F51, F 53, F 55, F 60, F 61.

Alloy Steel Thredolet – AS Thredolet
ASTM / ASME A/SA 182 F1/F5/F9/F11/F22/F91

Carbon Steel Thredolet – CS Thredolet
ASTMA 105/A694/ Gr. F42/46/52/56/60/65/70

Low Temperature Carbon Steel Thredolet – LTCS Thredolet
A350 LF3/A350 LF2
Value Added Service: Hot Dip Galvanizing
Electro polish

Dimension - Reducing Thredolets® - MSS SP97 Class 3000

NPS A B C
1/2 1
25.40
1.13/32
35.71
15/16
23.81
3/4 1.1/16
26.98
1.23/32
43.65
1.5/32
29.36
1 1.5/16
33.33
2
50.80
1.7/16
36.51
1.5/16
33.33
2.9/16
65.08
1.3/4
44.45
1.3/8
34.92
2.27/32
72.23
2
50.80
2
38.10
3.15/32
88.10
2.9/16
65.08
1.13/16
46.03
4.1/16
103.18
3
76.20
3 2
50.80
4.13/16
122.23
3.11/16
93.66
2.1/8
53.975
5.7/32
132.55
4
101.6
4
57.15
5.31/32
151.60
4.3/4
120.65
5 2.5/8
66.67
7.5/16
185.73
5.9/16
141.28
6 2.3/4
69.85
8.5/8
219.07
6.11/16
169.86
NPS A B C
General notes:
  • Dimensions: Top Row in Inches / Bottom Row in millimeters.
  • Root Gap - X - "Space" for welding the O'let is raised off the run pipe to establish proper weld gap by placing spacers, e.g. welding rods, under the fitting. This provides a uniform welding gap between the curvature of the run and base of fitting.
  • Threaded Ends are in accordance with ASME B1.20.1. Design per MSS SP-97.
  • Source comes from Bonney Forge (except the sizes in millimeters).
  • Thredolet® is a registered name. Another often used name is Threaded Outlet.
