Triton Alloys Inc also supplies a complete productionrange of SS 310/310S Buttweld Fittings and flanges pipes at the current time, SS 310/310S Seamless Pipes can be supplied accurate length & sizes or as per costumers requirment..

Our organization is involved in manufacturing, exporting, trading and supplying a extensive range of Stainless Steel Plates to our clients. Used in various industrial applications, these plates are manufactured by the experienced professionals from high-quality raw material and advanced technology. We are leading manufacturer and suppliers of stainless steel 310/310S grade and stainless steel 310/310S grade buttweld pipe fittings, forged fittings and flanges in India. We Manufacture and Supply a wide range of SS 310/310S Pipe Fittings such as SS 310/310S Reducer, SS 310/310S Elbow, SS 310/310S Tee, SS 310/310S Cross, SS 310/310S Stub Ends and SS 310/310S Pipe Bends.SS 310/310S can be substituted for Type 301 in many applications. We are an eminent organization engaged in manufacturing, supplying and exporting a quality assured array of Stainless Steel Pipes. Under the offered array, we provide Stainless Steel Seamless Pipe fittings, Stainless Steel Welded Pipe fittings. The offered pipes are known for being in-line with internationally laid quality norms as these are manufactured using high grade raw material. We also test these pipes prior to dispatch so as to ensure their flawlessness. We supply SS 310/310S at lowest shipping cost. Stainless steel is corrosion resistance so it can used in any environment. We supply a wide range of SS 310/310S pipe bends in both standard and non standard sizes .Its bending radius is upto 1D to 10D or at costumers requirment size, made in compliance with International quality and safety standards.We can dispatch your Order on the following day after the order is placed of various standard size and type 310/310S pipe Fittings, 310/310S Flanges and 310/310S Pipe Bends.Our specialty is to manufacture and supply large size Fabricated & Durability tested mm elbows, 310/310S reducers, and 310/310S tees.


Specification :


Specifications ASTM B366, ASME SB366
 size Seamless Butt Weld Fittings: 1/2" - 10"
Welded Butt Weld Fittings: 1/2" - 48"
 Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
 Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
 Types 90º Elbows, 45º Elbows, Tees, Crosses, Reducers, Pipe Cap, Stub End, Pipe Bend
DIN Standard Available DN15-DN1200
 Elbow Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D.
Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Manufacturing process Push, Press, Forge, Cast, etc.
 Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Origin & Mills Japanese, Indian, USA, Korean, European, Ukraine, Russian



SS 310S Buttweld Fittings Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 310 1.4841 S31000 SUS 310 310S24 20Ch25N20S2 X15CrNi25-20
SS 310S 1.4845 S31008 SUS 310S 310S16 20Ch23N18 X8CrNi25-21

SS 310S Buttweld Fittings Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
SS 310 0.015 max 2 max 0.015 max 0.020 max 0.015 max 24.00 – 26.00 0.10 max 19.00 – 21.00 54.7 min
SS 310S 0.08 max 2 max 1.00 max 0.045 max 0.030 max 24.00 – 26.00 0.75 max 19.00 – 21.00 53.095 min

SS 310S Buttweld Fittings Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
7.9 g/cm3 1402 °C (2555 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 40 %


Types of Buttweld Fittings Available


Buttweld Fittings

Long Radius Elbow

Buttweld Fittings

Short Radius

Buttweld Fittings

Long Radius Elbow

Buttweld Fittings

Short Radius Elbow

Buttweld Fittings

Long Radius Elbow

Buttweld Fittings

ASME B16.9 SS 180° Short Radius Elbow

Buttweld Fittings

1D Elbow

Buttweld Fittings

1.5D Elbow

Buttweld Fittings

3D Elbow

Buttweld Fittings

Seamless Buttwelding 180° Returns

Buttweld Fittings

Pipe Nipples

Buttweld Fittings

Lateral



Buttweld Fittings Applications Industries


ASME B16.9 Degree Forged are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of Buttweld Fittings Degree Forged through a worldwide network of stock-keeping branches. Buttweld Forged is use in various industries like :

  • Buttweld Fittings uses in Paper & Pulp Companies
  • Stainless Steel Buttweld Fittings uses in Oil and Gas Industry
  • Buttweld Fittings Pipe Forged uses in Chemical Refinery
  • Alloy Steel Threaded Elbowuses in Pipeline
  • Buttweld Buttweld Fittings Pipe Forged uses in High Temperature Application
  • Buttweld Fittings uses in Water Pipe Line
  • ANSI B16.9 Buttweld Fittings Pipe Forged can be used in Nuclear power plants
  • Buttweld Fittings usefule for High Pressure Applications
  • Buttweld Fittings Long Radius Forged uses in Fabrication and welding Job
  • Buttweld Fittings uses in Food Processing and Dairy Industries
  • Buttweld Fittings Short Radius Forged uses in boiler & heatexchangers

Marking & Packing


Our Nickel Alloy 2.4066 round bars are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All Nickel Alloy UNS N02200 bar are marked with Grade, Lot No, Size and our trade mark. We can also make custom marking on our products on Special request from Purchaser.


Quality Assurance


Triton Alloys Inc all Nickel Alloy 200 round bars, Nickel Alloy 200 bright bars and Nickel 200 hex bars are subject to strict inspection at each stage starting from material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, DIN, EN, and JIS codes and standards. We can also appoint official certified Inspection Agencies upon request of our clients so that they can witness the material reports, dimensions and quality conformity of products.
