ASTM F593 Bolts, F593C Bolt, SS F593 Bolts Fastener, Grade F593 Bolts Dimensions, ASTM F593C Hex Bolts, ASTM F593D Flange Bolts, ASTM F593G Socket Head Cap Screws, SS Bolts Nuts, ASTM F593D Bolt, ASTM F593 Bolts Specifications, Types Of ASTM F593 Bolts, ASTM F593 SS Hex Head Bolt Supplier in Mumbai and India
ASTM F593 bolts are extensively used for high-temperature and high-pressure applications. These ASTM F593C Bolts are efficiently used in various commercial and industrial factors. These ASTM F593C Hex Bolts are highly weldable, and they are made of high-quality material. These bolts are enriched with excellent properties and characteristics.
Chemical composition:
These ASTM F593 316 SS Bolts are made from a great combination of various elements. The chemical composition includes high amounts of chromium, nickel, and carbon, and the grade also includes manganese, phosphorus, sulfur, silicon, molybdenum, etc. These elements are highly malleable and provide extreme protection from various chemical reactions.
Specification :
| F593 Bolt grade |
|
| Size Metric of Stainless Steel F593 Bolts |
|
| ASTM F593 Hex Bolts Sizes in Inch |
|
| F593 Stainless Fasteners manufacturing process and sizes |
|
| Standard length of ASTM F593 Bolts | 3 mm to 200 mm |
| Stainless F593 Bolts & Screws US Threads | METRIC, BSW, Unified national fine (UNF), Unified national extra fine (UNEF), UNJC, UNJF, UNR, BSF, UNK, Unified national coarse (UNC), Constant-pitch threads |
| ASTM F593 Bolts UTS - Unified Thread Standard | UNC, UNS, UNF, NPT, NPTF, UNEF |
| ASTM F593 Bolts Head drive | Phillips/Slot, Phillips, Slotted, Six-Lobe, etc |
Chemical Composition of ASTM F593 Grade Bolts :
| Element | Carbon | Phosphorus | Manganese | Nickel | Sulfur | Silicon | Molybdenum | Copper | Chromium |
| Type 304 | 0.08% | 0.045% | 2.00% | 8.0 to 10.5% | 0.030% | 1.00% | - | 1.00% | 18.0 to 20.0% |
| Type 316 | 0.08% | 0.045% | 2.00% | 10.0 to 14.0% | 0.030% | 1.00% | 2.00 to 3.00% | - | 16.0 to 18.0% |
Mechanical Composition of Grade 36 ASTM F1554 Bolt :
| F593 Bolt Alloy Group | Condition | Marking on Bolt | Sizes | Tensile Strength, ksi | Yield Strength, ksi min | Rockwell Hardness |
|---|---|---|---|---|---|---|
| Group 1 | AF | F593A | 1/4 to 1-1/2 | 65 to 85 | 20 | B85 max |
| A | F593B | 1/4 to 1-1/2 | 75 to 100 | 30 | B65 to 95 | |
| CW1 | F593C | 1/4 to 5/8 | 100 to 150 | 65 | B95 to C32 | |
| CW2 | F593D | 3/4 to 1-1/2 | 85 to 140 | 45 | B80 to C32 | |
| Group 2 | AF | F593E | 1/4 to 1-1/2 | 65 to 85 | 20 | B85 max |
| A | F593F | 1/4 to 1-1/2 | 75 to 100 | 30 | B65 to 95 | |
| CW1 | F593G | 1/4 to 5/8 | 100 to 150 | 65 | B95 to C32 | |
| CW2 | F593H | 3/4 to 1-1/2 | 85 to 140 | 45 | B80 to C32 |
Types of ASTM Bolts Available
Hex Bolts
Anchor Bolts
Stud Bolts
Washers
Nuts
U Bolts
Threaded Bar
Screws
Fastener Applications Industries
ASTM F593 bolts are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of ASTM F593 bolts through a worldwide network of stock-keeping branches. F593 bolt is use in various industries like :
- Fastener uses in Paper & Pulp Companies
- Stainless Steel Fastener uses in Oil and Gas Industry
- Fastener Pipe Forged uses in Chemical Refinery
- Alloy Steel Threaded Elbowuses in Pipeline
- Fastener Pipe Forged uses in High Temperature Application
- Fastener uses in Water Pipe Line
- ANSI B16.9 Socket Weld Fittings Pipe Forged can be used in Nuclear power plants
- Fastener usefule for High Pressure Applications
- Fastener Long Radius Forged uses in Fabrication and welding Job
- Fastener uses in Food Processing and Dairy Industries
- Fastener Short Radius Forged uses in boiler & heatexchangers
Marking & Packing
Our ASTM F593 bolts are packaged to ensure that there is no damage during transit. In case of exports, standard export packaging is done in wooden cases. All ASTM bolts are marked with Grade, Lot No, Size and our trade mark. We can also make custom marking on our products on Special request from Purchaser.
Quality Assurance
Triton Alloys Inc all ASTM F593 bolts, ASTM F593C bolts and ASTM F593D bolts are subject to strict inspection at each stage starting from material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, DIN, EN, and JIS codes and standards. We can also appoint official certified Inspection Agencies upon request of our clients so that they can witness the material reports, dimensions and quality conformity of products.
